35 KV Up to 10000KVA New Energy Prefabricated Substation

Overview

Voltage:	Up to 35KA
Rated Power:	Up to 10000KVA
Primary Voltage:	6 kV, 10 kV, 11 kV, 15 kV, 20 kV, 22 kV, 33 kV, 34.5 kV, 35 kV
Secondary Voltage:	220 V, 380 V, 400 V, 480 V
Core material:	Copper/Aluminum
Cooling Methods:	ONAN/ONAF/KNAN
Transformer Oils:	Mineral oil/FR3/Silicone oil
Operational Environment:	Heat/Cold/Earthquake/Corrosive
OEM & ODM:	Color & Logo

Description

Our Prefabricated Compact Substation is a factory-assembled power distribution solution that integrates high-voltage switchgear, distribution transformer, and low-voltage switchgear into a single compact enclosure. Designed with advanced manufacturing techniques and a modular layout, it features a fully enclosed and insulated structure, effective ventilation and cooling systems, and robust anti-corrosion protection, ensuring reliable performance even in demanding outdoor environments.

Applications

• Urban & Rural Power Distribution – residential communities, schools, hospitals, and commercial complexes.

• Industrial Facilities – factories, manufacturing plants, and logistics centers.

• Infrastructure Projects – airports, seaports, metro systems, and rail transit.

• Renewable Energy – photovoltaic (PV) and wind power plants, ensuring stable and efficient grid connection.

Advantages

• High efficiency: Advanced power conversion technology ensures power conversion efficiency above 99%, reducing energy losses.

• Modular and flexible design: Supports scalable configuration to meet diverse project requirements.

• Intelligent monitoring: Equipped with Battery Management System (BMS) and remote monitoring for real-time supervision and control.

• Safe and reliable: Proven stability under extreme environmental conditions, ensuring long-term performance.

• Easy installation and maintenance: Integrated structure reduces on-site construction and minimizes routine maintenance needs.

• Space-saving and compact: All-in-one design integrates HV switchgear, transformer, and LV switchgear, optimizing land use.

• Wide adaptability: Suitable for urban distribution, industrial facilities, infrastructure, and renewable energy projects (PV and wind).
