Up to 35kV Up to 5000kVA Prefabricated Compact Substation with Dry Type Transformer
Voltage: Up to 35 kV
Rated Power: Up to 5000 kVA
Applications: Renewable energy projects, Infrastructure projects, Industrial facilities, Commercial buildings, etc.
Production Standards: GB, IEC, IEEE, UL, CE, ASTA
Overview
| Voltage: | Up to 35 kV |
| Rated Power: | Up to 5000 kVA |
| Primary Voltage: | 6 kV, 10 kV, 11 kV, 15 kV, 20 kV, 22 kV, 33 kV, 34.5 kV, 35 kV |
| Secondary Voltage: | 220 V, 380 V, 400 V, 480 V |
| Core material: | Copper/Aluminum |
| Cooling Methods: | AN/AF |
| Operational Environment: | Heat/Cold/Earthquake/Corrosive |
| OEM & ODM: | Color & Logo |
Description
Our Compact Substation is a prefabricated, all-in-one power distribution solution that integrates high-voltage switchgear, distribution transformer, low-voltage switchgear, and protective enclosure into a single, compact unit. Engineered for safety, reliability, and efficiency, it delivers complete power transformation, distribution, control, protection, and communication functions, while its modular and flexible design ensures quick installation, minimal footprint, and easy relocation. By placing the substation closer to the load center, it improves power quality, reduces energy loss, and enhances overall grid reliability, making it an ideal choice for modern urban, industrial, and infrastructure projects.
Applications
• Residential & Commercial – Housing, high-rise buildings, community centers, offices.
• Infrastructure – Airports, railways, highways, subways, ports.
• Energy & Industry – Renewable energy stations, oil fields, mining, factories.
• Construction – Tunnels, temporary sites, mobile projects.
Advantages
• High Efficiency & Reliability: Full-range protection and advanced integration improve power quality and reduce downtime.
• Compact & Cost-Saving: Small footprint and prefabricated design reduce construction time and infrastructure costs.
• Flexible Power Supply: Supports ring network, dual power, terminal supply, and high-voltage metering.
• Safe & Secure: Fully enclosed, grounded shell with protective mesh prevents accidents.
• Efficient Heat Dissipation: Chimney-effect ventilation ensures stable operation under various conditions.
• Customizable & Adaptable: Casings in cold-rolled steel, aluminum-zinc, stainless steel, or GRC; multiple layout options.
• Easy Installation & Maintenance: Quick on-site deployment, easy relocation, and minimal routine maintenance.
FAQ
- Installation guidance & technical support available on-site or online.
- 30-minute response time to any customer inquiry.
- 2-hour commitment to provide a preliminary solution.
- 48-hour on-site dispatch if required.
